¿Á³»ÄÉÀ̺í

¿Á³»ÄÉÀ̺í

01. Application

  • Local area network.
  • FTTH application.
  • Inter building & communication link

02. Features

  • Exxential for indoor use
  • Decrese in installation cost
  • Aramid yarn reinforcement for fiber protection.
  • Rip cord for easy jacket removal
  • Flame retardant PVC or LSZH outer jacket.

03. Cable Data

1) Mechanical Data
Mechanical Data
Jacket Materials Storage Temperature Operation Temperature
PVC, LSZH, PE -40¡É~+80¡É -20¡É~+80¡É
2) Fiber Type
Fiber Type
Items Singlemode (1310/1550§­) Multimode (850/1300§­)
9/125§­ 50/125§­ 62.5/125§­
Core Diameter (§­) 9 50 62.5
Cladding Diameter (§­) 125 125 125
Coating Diameter (§­) 245 245 245
Buffer Diameter (§­) 900 900 900
3) Optical Transmission Performance
Optical Transmission Performance
Items Singlemode (1310/1550§­) Multimode (850/1300§­)
9/125§­ 50/125§­ 62.5/125§­
Maximum Attenuation 0.4/0.3 3.0/1.0 3.5/1.0
Typical Attenuation 0.5/0.4 3.0/1.0 3.0/1.0
Minimum Bandwidth (§Ö §°) N/A 500/500 200/600

04. Ordering Information
